Use the wheel to get close and the brake lever for final adjustment. Tighten the wheel until the drum barely goes on, then pump the brake lever a few times. If the self-adjustment is working the lever will only come up about half-way. As you drive the car occasionally you'll notice that parking brake lever got tighter as the wheel moves a notch.

Up front in the area of the console look for blue tape around the wire harness. That's where you should find the female plug with 2 wires. Put a jumper across the plug and you should then have power back at the tank for the electric pump. It's a good idea to put an inertia switch in the jumper loop to shut off the pump in the event of a crash.

Sorry, this 240Z dash is not in the car but here are pictures of the dash wiring and the unused connector that could deliver power back to a fuel pump. The wiring comes down the right side of the heater slider assembly with all the wiring to the fuse box and center console connections.
