@Zed Head u r right the remote starting works just by supplying 12v to the pin. Other jumper is not needed.
Also, i tested the voltage at the positive terminal of the coil (assuming ignition coil):
- At ON there is no voltage
- When I move the key to START i see 12v
Appreciate everyone patience so far guys. I think we are not far away from getting to the issue...
Also, why do u say the ignition relay is not in the starter circuit? The FSM page i posted clearly says there are 3 parts of the starter circuit Starter Relay, Ignition Relay (not Module - correction) and Inhibitor switch.
